This product has been discontinued by Alloy.
The Husky HUE-411S-CDU is a Class 1 Division 2 and UL508 entry-level industrial slimline unmanaged Ethernet switch. This five port device has 4x 100Base-TX RJ-45 and 1x SC multimode fibre optic ports, capable of transmitting data up to 2km.
The Husky series are cost effective, industrially hardened Ethernet switches, specifically designed to operate reliably in electrically harsh, demanding environments and in hazardous locations.
All models in the series share a common specification, which includes design features that provide high level of immunity to electromagnetic interference and power supply surges typically found in industrial plant environments. The switches are equipped with a terminal block to provide dual power inputs with reverse polarity protection. Husky switches provide an integrated power supply for a wide range of voltages (12 to 48V DC) for worldwide operability.
|•||Class 1 Division 2 Certified|
|•||Provides 4x 10/100 Mbps Ethernet ports with RJ-45 connectors|
|•||Provides 1x 100Mb Multimode Fibre Port with SC Connection|
|•||RJ-45 Ports support auto MDI/MDI-X crossover|
|•||Robust Aluminum case complying to IP-30 housing standard|
|•||Supports operating temperature -10°C to 70°C|
|•||DIN-Rail, Panel mount or desktop installation|
|•||Supports 12 to 48VDC redundant power with polarity reverse protection|
|•||Equipped with Redundant power inputs|
|•||Terminal block present for master and slave power|
|•||Total Ports: 5|
|•||RJ-45 Ports: 4x 10/100Mbps|
|•||Fibre Ports: 1x 100Mbps Multimode Port with SC Connection|
|•||Alarm Contact: 1A@24VDC|
|•||Dimensions: 30 mm (W) x 140 mm (H) x 95 mm (D)|
|•||Installation: DIN-Rail or Wall Mounted|
|•||Power Input: 12 to 48VDC, redundant power inputs|
|•||Power Consumption: 4.2W|
|•||Operating Temperature: -10 to 70 C|
|•||Storage Temperature: -40 to 85 C|
|•||Operating Humidity: 5% to 95% RH (Non-condensing)|
|•||Shock: IEC 60068-2-27|
|•||Vibration: IEC 60068-2-6|
|•||Free Fall: IEC 60068-2-32|
|•||MTBF: 608,891 hours based on Mil-Hdbk-217F, GB|
