discontinued
ALLOY
GBIC-SSC40
Gigabit Single Mode GBIC Module 1000Base-LX, 1310nm, 40Km
This product has been discontinued by Alloy.
The GBIC-SSC40 is a 1000Base-LX Multimode Fibre GBIC module that can be installed into switches supporting a gigabit based GBIC slot.
The GBIC-SSC40 is a 1000Mb Single Mode Fibre SFP module suitable for a wide range of switches supporting a GBIC interface. Distances of 40Km can be achieved.
The flexibility of the GBIC interface allows users the ability to interchange modules at their convenience. This allows administrators to upgrade their cabling infrastructure without the need to upgrade their switching equipment.
GBIC modules are hot-swappable adding another level of convenience for the administrator.
The flexibility of the GBIC interface allows users the ability to interchange modules at their convenience. This allows administrators to upgrade their cabling infrastructure without the need to upgrade their switching equipment.
GBIC modules are hot-swappable adding another level of convenience for the administrator.
| • | Up to 1.25Gb/s bi-directional data links | |
| • | 1310nm FP laser and PIN photodetector | |
| • | Standard serial ID information compatible with SFF-8053 | |
| • | Duplex SC optical interface | |
| • | Maximum distance of 40Km | |
| • | RoHS Compliant | |
| • | +3.3V/5V single power supply | |
| • | Temperature range: 0° to +70°C | |
| Interface | |
| • | 1000Base-LX Multimode Fibre |
| Data Rate | |
| • | 1.25Gbps |
| Distance | |
| • | Maximum 40Km |
| Fibre | |
| • | Receive Sensitivity: -22dBm |
| • | Transmit Power: -5 ~ 0dBm |
| • | Wavelength: 1310nm |
| Power | |
| • | Input Voltage: Max. 3.47V |
| • | Supply Current: Max. 300mA |
| Environmental | |
| • | Operating Temperature: 0° to 70° C |
| • | Storage Temperature: -40° to 85° C |
