The PW5130i3000-2U, an Eaton 5130 Series Line Interactive UPS, offers high-density power protection for critical loads, delivering more performance in less space at a value price. This 3kVA rated UPS has 9x IEC (8xC13, 1xC19) power backup outlets.

Eaton's PW5130i3000-2U Line Interactive UPS protects connected equipment from five of the most common power anomalies: failures, surges, sags, under-voltage and over-voltage. This versatile UPS offers the choice of 2RU rack mount or tower installation, and provides high-density power protection for critical loads up to 3kVA - delivering more performance in less space at a value price. The PW5130i3000-2U supplies pure waveform power, and has nine IEC style power outlets (1x IEC C19 16amp, 8x IEC C13 10amp). With an expandable battery capacity of 3kVA/2.7kW, the UPS will support connected devices for up to 10 minutes at 50% load. Voltage fluctuation is automatically corrected and stabilised, preserving battery capacity. Powerful surge suppression is provided via an ANSI C62.41 compliant integrated device. Comprehensive UPS monitoring and management is provided through a combination of LCD user interface, intuitive LanSafe power management and auto-shutdown software, and remote control and monitoring capabilities via a USB or serial RS-232 port, direct connection to an Ethernet network and the Internet for browser-based management and remote on/off and power off ROO/RPO capability. Further powerful management features are available via optional ConnectUPS-MS network management cards for Web, SNMP, Modbus/Jbus or serial connectivity.

The PW5130i3000-2U is a model from Eaton's 5130 Series of Pure Sinewave Line Interactive UPS. Models in the series offer up to 3kVA/2.7kW battery capacity. In addition to the features mentioned above, all models in the range offer the following powerful features: 0.9 output power factor providing more real wattage in less space; add up to four External Battery Modules (EBM) to extend the UPS battery runtime; hot-swappable batteries to increase UPS availability and minimise service time; Load Segment Control, enabling prioritised shutdown of non-essential equipment during outages, and options for 2RU and short depth 3RU rack cases for 3kVA UPS models. Finally, these further optional hardware items can be connected to a 5130 series UPS: Hot Swap Maintenance Bypass Switch (MBP) to avoid 'downtime' during service operations; FlexPDU for increased load distribution; Environmental Monitoring Probe(s) to monitor environmental factors such as humidity and temperature.
