Snom
SNOM-715
Gigabit Phone Entry level IP Phone
The new entry level device the snom 715 completes the snom Advanced Line of IP phones as a high-performance, high-end but low-price device.
The new entry level device the snom 715 completes the snom Advanced Line of IP phones as a high-performance, high-end but low-price device. The integrated Gigabit switch ensures that there will be no lag in PC connectivity and the integrated USB port enables the use of an optional WLAN dongle for wireless connectivity. With unparalled audio quality alongside the new functionality, the 715 is guaranteed to be a real hit.
The snom 715 has a four-line black and white graphical display featuring an intuitive interface with four context sensitive programmable function keys within a simple, user-friendly menu. The snom 715 has five programmable keys with built-in LEDs for visual call indication alerts. Each key is easily configured f or a variety of one-touch telephony functions such as speed dial, busy lamp field or multiple extension handling.
| • | Four-lines | |
| • | Backlit black and white display | |
| • | 5 freely programmable function keys with LEDs | |
| • | 4 contect-sensitive function keys | |
| • | Wideband HD audio | |
| • | Speakerphone | |
| • | Power over Ethernet (PoE) | |
| • | WLAN / Bluetooth headset ready | |
| • | Gigabit switch | |
| • | XML Minibrowser | |
| • | USB Port | |
| GENERAL INFORMATION | |
| • | Weight: Phone approx. 440g, footstand approx. 120g |
| • | Dimensions: approx. LxWxD without footstand 205x185x40 mm. With footstand 205x185x200/220 mm |
| • | Certification FCC Class B, CE marking |
| • | Safety: IEC 60950-1:2007 |
| • | Ethernet: 2 x IEEE 802.3/1 Gigabit switch |
| • | Power over Ethernet/PoE: IEEE 802.3af, Class 2 |
| • | Power: PoE or 5V DC power supply listed in the user guide (snom PN 00002730) available seperately |
| • | 1 x LAN, 1 x PC: RJ 45 |
| • | USB port: 1 x type A, USB 2.0 Hi/Full/Low Speed-compatible host interface |
| • | Handset: 4P4C connector |
| • | Headset: (wired) 4P4C connector (wireless via USB adapter or snom EHS Advanced - available seperately) |
| • | Color: Anthracite gray |
| USER INTERFACE | |
| • | Four-line display, BW, 128 x 48 pixels |
| • | 5 freely programmable keys, 4 variable function keys |
| • | Menu-driven user interface |
| • | Comfortable and intuitive menu structure |
| • | Localization (language, time, dial tone) |
| • | Call indication with LED |
| • | Selection of ring tones, VIP ring tones, integration of customized ring tones |
| • | LED indicators for missed calls, received messages, and calls on hold |
| • | Hands-free talking (speakerphone) |
| • | Multiple audio device support |
| • | Clock with automatic daylight-saving time |
| • | Indication of call duration |
| PHONE FUNCTIONS | |
| • | 4 identities/accounts |
| • | Directory with 1000 contact entries |
| • | Import/export of directory |
| • | Speed dialing |
| • | URL dialing |
| • | Local dial plan |
| • | Automatic Redial on Busy |
| • | Caller identification |
| • | Call waiting |
| • | Auto answer |
| • | Lists of missed, received and dialed calls |
| WEB SERVER | |
| • | Built-in HTTP/HTTPS server |
| • | Remote configuration/provisioning |
| • | Dialing from web interface |
| • | Password protection |
| • | Diagnostics (traces, logging, syslog) |
| SECURITY, QUALITY OF SERVICE | |
| • | HTTPS-Server/-Client |
| • | Transport Layer Security (TLS) |
| • | SRTP (RFC3711), SIPS, RTCP |
| • | VLAN (IEEE 802.1X) |
| • | LLDP-MED, RTCP-XR |
| • | VPN |
| CODECS, AUDIO | |
| • | Wideband audio |
| • | G.711 A-law, ยต-law |
| • | G.722 (wideband) |
| • | G.726, G.729AB, GSM 6.10 (FR) |
| • | Comfort Noise Generator (CNG) |
| • | Voice Activity Detection (VAD) |
| SIP | |
| • | RFC3261 compliant |
| • | UDP, TCP and TLS |
| • | Digest authentication |
| • | PRACK (RFC3262) |
| • | Error code indication |
| • | Reliability of provisional responses (RFC3262) |
| • | Early media support |
| • | DNS SRV (RFC3263), redundant server support |
| • | Offer/Answer (RFC3264) |
| INSTALLATION | |
| • | Automatic software updates |
| • | Automatic loading of settings via HTTP/ HTTPS/TFTP |
| • | Configurable through web interface |
| • | Remote management via TR-069/TR-111 |
| • | Easy WLAN binding via USB adapter (available seperately) |
| • | Static IP, DHCP support |
| • | NTP |
